Device Type
|
IP-camera
|
Connection type
|
wired
|
Installation location
|
inside, outside
|
Matrix resolution
|
2 Mpx (1920х1080)
|
Wi-Fi support
|
no
|
Video standard
|
IP
|
Type of instalation
|
wall, ceiling, overhead
|
Form factor
|
dome
|
Intended for use
|
home, house, office, store, warehouse, production
|
Matrix type
|
1/2.8″ CMOS
|
Recording speed
|
Main Stream 1080р – 25 fps, Sub Stream D1 – 25 fps
|
Camera motion sensor
|
program
|
Lens type
|
fixed
|
Focal length
|
2.8 mm
|
Viewing angle
|
110°
|
Optical zoom
|
1x
|
Digital zoom
|
1x
|
Light sensitivity
|
0.005 Lx F1.6
|
Light distance
|
30 m
|
Type of illumination
|
white light
|
Day-night mode
|
yes, ICR filter
|
Memory card slot
|
no
|
Built-in microphone
|
no
|
Built-in speaker
|
no
|
Video output
|
1xRJ45
|
Audio inputs
|
no
|
Audio outputs
|
no
|
Network output
|
1xRJ45
|
Network Interface
|
RJ -45 (10/100Base -T), IPv4, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, SMTP, FTP, DHCP, DNS, NTP, Multicast
|
PoE support
|
yes
|
PoE type
|
802.3af
|
Video compression
|
H.264, H.264+, H.265, H.265+
|
Alarm Inputs-Outputs
|
no
|
Alarm inputs
|
no
|
Alarm outputs
|
no
|
Modes
|
day/night (ICR) / AGC / BLC / HLC / DWDR / ROI / Privacy Masking
|
Streaming
|
2 streams
|
Built-in lightning protection
|
no
|
Additional functions of camera
|
smart IR, P2P, region of interest (ROI)
|
Moisture and dust protection
|
IP67
|
Vandal protection
|
no
|
Browsers
|
Chrome, Firefox, Safari, Edge, Opera
|
OS support
|
Windows, MAC OS, IOS, Android
|
Powered by batteries / rechargeable batteries
|
no
|
Integration with Ajax system
|
yes
|
Compatibility
|
ONVIF (Profile S/Profile T), CGI, P2P, Genetec
|
Consumption
|
5.3 W
|
Operating voltage
|
12V DC
|
Dimensions (WхHхD)
|
Ø 109х86 mm
|
Body color
|
white
|
Body material
|
metal, plastic
|
Weight
|
240 g
|
Temperature range
|
-40…+60°C
|
Producing country
|
China
|
Device class
|
economy
|
